16-port 10/100M Rackmount Industrial Ethernet Switch IES1016 manufacturer from China Shenzhen 3onedata Technology Co.,Ltd.

16-port 10/100M Rackmount Industrial Ethernet Switch

Price:	100.0~600.0 USD
Payment Terms:	T/T,WU
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: IES1016

Production Capacity: 10000

Delivery Date: 3 working days

Transmission Rate: 10/100Mbps

Type: Wired

Means of Transport: Ocean,Air

Packing: standard

Interface: Others

Application: Server

Brand Name: 3onedata

1. 10/100BaseT(X)(RJ45)
2. Support IEEE802.3/802.3u/802.3x
3. Store and Forward switching process type
4. Support auto negotiation speed.

Specification

Interface

RJ45 Ports: 10/100BaseT(X) auto connection, Full /Half duplex or force work mode, and support MDI/MDI-X connection

LED Indicators: PWR, Link/ACT, 100M

Technology

Standard:IEEE802.3\IEEE802.3x\IEEE802.3u

Forwarding and Filtrate Rate: 148810pps

transmit type :Store and Forward switching process type

Support 8K MAC Address

Power

Input Voltage: DC100~300V or AC85~264V

Input Current: 0.1A

Overload Current Protection

Connection: 3 bit terminal block

Mechanical

Dimensions (L×W×H): 441.6×44.6×206.9mm

Packaging: IP 30 protection, metal case

Installation: 19-inch rack mount

Environmental

Operating Temperature: -10°C to 60°C

Storage Temperature : -40°C to 85°C

Ambient Relative Humidity: 10% to 95% (non-condensing)

Approvals

EMI:FCC Part 15, CISPR (EN55022) class A

EMS: EN61000-4-2(ESD), Level 4

EN61000-4-3(RS), Level 4

EN61000-4-4(EFT), Level 4

EN61000-4-5 (Surge), Level 4

EN61000-4-6 (CS), Level 4

EN61000-4-8,100A/m

EN61000-4-12

Shock: IEC 60068-2-27

Free Fall: IEC 60068-2-32

Vibration: IEC 60068-2-6

Warranty: 5 years

Approvals: FCC,CE, RoHS approvals
