2-Port RS-232/485/422 to Ethernet Serial Server NP302 manufacturer from China Shenzhen 3onedata Technology Co.,Ltd.

2-Port RS-232/485/422 to Ethernet Serial Server

Payment Terms:	T/T,WU
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: NP302

Production Capacity: 10000

Brand Name: 3onedata

Means of Transport: Air

Delivery Date: 3 working days

1.Support 300bps-460.8Kbps
2.Support TCP, UDP, ARP, ICMP, HTTP, TELNET and DHCP protocol
3.Support across gateway, router communication

Features

1. Adopt 32 bit ARM processor, 125 DMIPS manage ability

2. 2 serial ports, with support for RS-232/RS-485/RS-422

3. Support 10/100M Ethernet

4. Support 300bps-460.8Kbps

5. Support TCP, UDP, ARP, ICMP, HTTP, TELNET and DHCP protocol

6. Support across gateway, router communication

7. Support standard TCP/IP SOCKET

8. Support Virtual serial driver access and auto connect after the network disconnect

9. Choice of configuration methods: Windows, TELNET and WEB

10. Support DIN-Rail or wall mounting installation

Introduction

NP302 series can conveniently connect up to 2 serial devices to an Ethernet, allowing you to network your existing serial devices with only basic configuration. With NP302 series, you can both centralize the management of your serial devices, and distribute management hosts over the network.

NP302 series can be used to connect different devices for remote management, each serial port operates independently to provide maximum versatility, each port can be operate in Driver, TCP Server, and TCP Client mode independently.

Specification

Ethernet

Number of ports:1

Standard:10/100Base-T(X)

Speed:10/100M auto-sensing

Working mode: half /full duplex

Working: TCP Server, TCP Client, UDP and Real COM driver

Memory: Most 32Kbyte

Transmission: 100m

Electromagnetism isolate: 1KV

Connector: RJ45

Serial

Standard: RS-232/RS-485/RS-422

Number of ports: 2

Signals: RS-232:DCD,RXD,TXD,DTR,GND,DSR,RTS,CTS

RS-485:Data+,Data-,GND

RS-422:TXD+,TXD-,RXD+,RXD-,GND

Parity: None, Even, Odd, Space, Mark

Data bits: 5bit, 6bit, 7bit, 8bit

Stop bits: 1, 1.5, 2

Baud rate: 300bps ~ 460.8Kbps

Flow control: RTS/CTS or XON/XOFF

Direction control: RS485 side adopt ADDC technology, auto text and control data transfer direction

Loading: RS-485/422 side support 32 nodes (customize 128 nodes) loopback

Transmission: RS-485/422 side 1200M,

RS-232 port 15M

Interface protection:1500W surge protection,

15KV ESD protection

Software

Network protocols: Support TCP, UDP, ARP, ICMP, HTTP, TELNET and DHCP

Driver support: Windows Real COM driver

(Windows NT/2000, Windows XP/2003)

Configuration options: Windows, TELNET and WEB

Power

Power input: 5VDC

Consumption: <1W

Environment

Working temperature:-20°C~60°C

Storage temperature:-25°C~85°C

Humidity: Relative humidity 5% to 95%

Appearance

Color: Black

L×W×H: 113.0mm×77.0mm×23.5mm

Material: Iron (Shell)

Weight: 240g

Warranty: 5 years

Approvals: FCC, CE, RoHS approvals
